运动版背驼房车配置表 | |||||||
尺寸Overall Size | 3560*2220*1400(升顶后pop up to 2250)mm | 整备质量Curb Weight(KG) | 660KG(全配 Full Equipped) | 配置选项 | |||
匹配底盘Marched Chassis | 福特 Ford Ranger | 车身结构 Body Structure | 铝合金骨架复合板 Al Frame work composite panel | ||||
类别Category | 配置名称Equipment | 配置规格 Specifications | 数量QTY | 单位 | |||
车身RV Body | 支撑腿 Support Jacks | 手动支撑腿 Manually operate support Jacks | 4 | 只 | ● | ||
上车踏步 Entry Step |
底板/侧围/顶盖/前后围 Floor panel ,Side wall, top cover, Front/Rear wall | 1 | 件 | ● | |||
上车门 Entry door | 外形尺寸:575*1050,带纱门 Exterior size :575*1050mm ,door with midge proof mesh | 1 | 套 | ● | |||
侧窗左边 left window | 外形尺寸:500*350,带纱窗 Exterior size :500*350mm ,door with midge proof mesh | 1 | 扇 | ● | |||
侧窗右边 right windows |
外形尺寸:350*280,带纱窗 Exterior size :355*280mm ,door with midge proof mesh | 1 | 扇 | ● | |||
前窗 Front Window | 外形尺寸:500*350mm,带纱门 Exterior size :500*350mm ,door with midge proof mesh | 1 | 扇 | ● | |||
煤气瓶舱门 Gas Bottle Door |
外形尺寸:330*450 Exterior size :330*450mm | 2 | 扇 | ● |
